PIE6540PTU 3.0
PIE6540PTU 3.0
Specification
FEATURES
| Rapid preheating Yes | Bridge Function No data in PDM for HQF | Bridge bay size (mm) NA | ||||||||||||||||||
| ChildLock Yes | Energy saving Yes | Heat maintainer Yes | ||||||||||||||||||
| Hob finish No bevelled | Front left heating zone dimension (cm) 21 | Left front zone energy consumption FL 188.9 Wh/kg | ||||||||||||||||||
| Front left heating zone power rating (kW) 2/2.8 | Left Front Induction Zone Booster No data in PDM for HQF | Left front zone type FL Induction | ||||||||||||||||||
| Rear left heating zone dimension (cm) 16 | Left rear zone energy consumption RL 188.9 Wh/kg | Rear left heating zone power rating (kW) 1.2/1.4 | ||||||||||||||||||
| Left rear induction zone booster No data in PDM for HQF | Left rear zone type RL Induction | Minute minder Yes | Mounting data No data in PDM for HQF | Number of Booster 4 | Number of power levels 9 | |||||||||||||||
| Overflow detection Yes | Overheat detection Yes | Power Choice Yes | Power Management Yes | Residual heat indicator Yes | Front right heating zone dimension (cm) 16 | Right front zone energy consumption FR 188.9 Wh/kg | Front right heating zone power rating (kW) 1.2/1.4 | Right front induction zone booster No data in PDM for HQF | Right front zone type FR Induction | Rear right heating zone dimension (cm) 21 | Right rear zone energy consumption RR 188.9 Wh/kg | Rear right heating zone power rating (kW) 2/2.8 | Right Rear Induction Zone Booster No data in PDM for HQF | Right rear zone type RR Induction | Silent work Yes | Small object detection Yes | Temperature limiter Yes | Auto switch off Yes | Timer Yes | Control type +/- |
Equipment
| Power indicator lamp Yes |
Technical data
| Frequency 50 | Can be built flush with the top Yes | Connection type 3N~230/400 V |
| Cut out size - depth 49 cm | Cut out size - width 56 cm | Display color Red |
| Edge finish C-cut | Gross volume 0.0525 m³ | Total power of hob 7.35 kW |
| In-furniture depth 5.4 cm | Middle induction zone Booster No data in PDM for HQF | Net depth 52.2 cm |
| Net height 6 cm | Net weight 7.85 kg | Net width 59.2 cm |
| Number of heating elements 4 | Position Of Connection Cable Middle - rear | Power Supply Voltage 230V / 400V |
| Power Supply Voltage 230_400V | Hob type Induction |
